Transformer 2 500 kVA 10/0.4 kV — hermetic oil-immersed (TMG type) and cast-resin dry-type (TSL type)
2 500 kVA power transformers from the partner factory: hermetic oil-immersed, wound-core and amorphous-core, cast-resin dry-type. HV 6; 6.3; 10; 10.5 or 11 kV, LV 0.4 kV, vector group Dyn11 or Yyn0. Hermetic oil-immersed units are the same type as TMG, cast-resin dry-type units the same type as TSL; dimensions and connections are agreed for your project.
- LV rated current, 0.4 kV
- 3 608 A
- HV rated current, 10 kV
- 144.3 A
- HV rated current, 6 kV
- 240.6 A
- Active power at cos φ = 0.8
- 2 000 kW
- Active power at cos φ = 0.9
- 2 250 kW
- Active power at cos φ = 0.95
- 2 375 kW
- Manufacturing time
- 25–45 days
Current is calculated as I = S / (√3 · U), active power as P = S · cos φ. Actual load depends on the nature of the consumers.
2 500 kVA versions
| Series | Type | Eff. class | No-load losses, W | Load losses, W | Uk, % | Annual no-load losses, kWh |
|---|---|---|---|---|---|---|
| S13 | oil-immersed | 3 | 1 600 | 21 200 | 5,0 | 14 016 |
| S20 | oil-immersed | 2 | 1 440 | 16 960 | 5,0 | 12 614 |
| S22 | oil-immersed | 1 | 1 280 | 15 270 | 5,0 | 11 213 |
| MRL (S22) | oil-immersed, wound core | 1 | 1 280 | 15 270 | 5,0 | 11 213 |
| SH15 | oil-immersed, amorphous core | 3 | 865 | 21 200 | 5,0 | 7 577 |
| SH25 | oil-immersed, amorphous core | 1 | 670 | 15 450 | 5,0 | 5 869 |
| SCB10 | dry-type | — | 3 600 | 17 100 | 6,0 | 31 536 |
| SCB13 | dry-type | — | 2 590 | 15 400 | 6,0 | 22 688 |
| SCB14 | dry-type | 2 | 2 450 | 15 445 | 6,0 | 21 462 |
| SCB18 | dry-type | 1 | 2 080 | 15 445 | 6,0 | 18 221 |
Data from the partner factory's catalogue. Energy efficiency class per GB 20052-2024. Annual no-load losses = no-load losses × 8760 h. Where load losses are given as two figures, the first is for Dyn11, the second for Yyn0.
