Slurry pump spare parts
The pump casing lasts for years, while the wet end on abrasive slurry wears out in weeks or months. We supply impellers, volutes, throatbushes and liners for common sizes, including replacements for departed European suppliers.
We make any pump parts to your drawings — housing parts, impellers, shafts, sleeves and seals, including for pumps not in the catalogue.
What you should know
- Material A05 — iron with about 27 % chromium, hardness after heat treatment HRC 58+
- For fine and corrosive media — rubber parts
- We make parts to your drawings: we cast, machine and check dimensions at the factory
- We select by the pump nameplate marking or by the part's catalogue number
- It pays to replace impeller, volute, throatbush and liner as a set
Send a photo of the nameplate or a drawingWe will tell you whether the factory can make the part to your size, how much it costs and how long until shipmentSend request
Sizes
| Pump size | Parts | Impeller weight, kg | Material |
|---|---|---|---|
| 1.5/1B-AH | impeller, volute, throatbush, liner | 3,9 | A05 (high-chrome cast iron) |
| 2/1.5B-AH | impeller, volute, throatbush, liner | 6,3 | A05 (high-chrome cast iron) |
| 3/2C-AH | impeller, volute, throatbush, liner | 17 | A05 (high-chrome cast iron) |
| 4/3C-AH | impeller, volute, throatbush, liner | 23,8 | A05 (high-chrome cast iron) |
| 6/4D-AH, 6/4E-AH | impeller, volute, throatbush, liner | 69 | A05 (high-chrome cast iron) |
| 8/6E-AH, 8/6F-AH | impeller, volute, throatbush, liner | 190 | A05 (high-chrome cast iron) |
| 10/8F-AH | impeller, volute, throatbush, liner | 373 | A05 (high-chrome cast iron) |
| 10/8ST-AH | impeller, volute, throatbush, liner | 373 | A05 (high-chrome cast iron) |
| 12/10ST-AH | impeller, volute, throatbush, liner | 490 | A05 (high-chrome cast iron) |
| 14/12ST-AH | impeller, volute, throatbush, liner | 920 | A05 (high-chrome cast iron) |
| 16/14TU-AH | impeller, volute, throatbush, liner | 1123 | A05 (high-chrome cast iron) |
| 20/18TU-AH | impeller, volute, throatbush, liner | 2585 | A05 (high-chrome cast iron) |
| 3/2D-HH | impeller, volute, throatbush, liner | 78 | A05 (high-chrome cast iron) |
| 4/3E-HH | impeller, volute, throatbush, liner | 126 | A05 (high-chrome cast iron) |
| 6/4F-HH | impeller, volute, throatbush, liner | 296,5 | A05 (high-chrome cast iron) |
| 10/8E-M | impeller, volute, throatbush, liner | 210,5 | A05 (high-chrome cast iron) |
| 40PV-SP | impeller, volute, throatbush, liner | 4,6 | A05 (high-chrome cast iron) |
| 65QV-SP | impeller, volute, throatbush, liner | 15,5 | A05 (high-chrome cast iron) |
| 100RV-SP | impeller, volute, throatbush, liner | 41 | A05 (high-chrome cast iron) |
| 150SV-SP | impeller, volute, throatbush, liner | 90 | A05 (high-chrome cast iron) |
| 200SV-SP | impeller, volute, throatbush, liner | 108,6 | A05 (high-chrome cast iron) |
