Transformer 160 kVA 10/0.4 kV — hermetic oil-immersed (TMG type) and cast-resin dry-type (TSL type)
160 kVA power transformers from the partner factory: hermetic oil-immersed, wound-core and amorphous-core, cast-resin dry-type. HV 6; 6.3; 10; 10.5 or 11 kV, LV 0.4 kV, vector group Dyn11 or Yyn0. Hermetic oil-immersed units are the same type as TMG, cast-resin dry-type units the same type as TSL; dimensions and connections are agreed for your project.
- LV rated current, 0.4 kV
- 231 A
- HV rated current, 10 kV
- 9.2 A
- HV rated current, 6 kV
- 15.4 A
- Active power at cos φ = 0.8
- 128 kW
- Active power at cos φ = 0.9
- 144 kW
- Active power at cos φ = 0.95
- 152 kW
- Manufacturing time
- 25–45 days
Current is calculated as I = S / (√3 · U), active power as P = S · cos φ. Actual load depends on the nature of the consumers.
160 kVA versions
| Series | Type | Eff. class | No-load losses, W | Load losses, W | Uk, % | Annual no-load losses, kWh |
|---|---|---|---|---|---|---|
| S13 | oil-immersed | 3 | 200 | 2 310 / 2 200 | 4,0 | 1 752 |
| S20 | oil-immersed | 2 | 180 | 1 850 / 1 760 | 4,0 | 1 577 |
| S22 | oil-immersed | 1 | 160 | 1 665 / 1 585 | 4,0 | 1 402 |
| MRL (S22) | oil-immersed, wound core | 1 | 160 | 1 665 / 1 585 | 4,0 | 1 402 |
| SH15 | oil-immersed, amorphous core | 3 | 100 | 2 310 / 2 200 | 4,0 | 876 |
| SH25 | oil-immersed, amorphous core | 1 | 80 | 1 870 / 1 780 | 4,0 | 701 |
| SCB10 | dry-type | — | 540 | 2 130 | 4,0 | 4 730 |
| SCB13 | dry-type | — | 385 | 1 910 | 4,0 | 3 373 |
| SCB14 | dry-type | 2 | 365 | 1 915 | 4,0 | 3 197 |
| SCB18 | dry-type | 1 | 310 | 1 915 | 4,0 | 2 716 |
Data from the partner factory's catalogue. Energy efficiency class per GB 20052-2024. Annual no-load losses = no-load losses × 8760 h. Where load losses are given as two figures, the first is for Dyn11, the second for Yyn0.
How we work
- Questionnaire or specificationSend us a questionnaire, specification or drawing. Within one working day we will reply with an indicative price and lead time; the firm price follows after engineering review.
- Engineering to your requirementsThe factory prepares drawings to your specification: voltages, vector group, losses, dimensions, bushings. We agree them with you before production starts.
- Contract and prepaymentWe work under a supply contract with a Russian legal entity. The manufacturing time is fixed in the contract.
- Manufacturing 25–45 daysStandard manufacturing time at the factory is 25–45 calendar days from production start.
- Factory acceptanceFactory acceptance tests. We send photos and video of your transformer and the test reports before shipment.
- Delivery and documentsDelivery to site, customs clearance, technical passport and test reports in Russian.
Partner factory
- Factory quality management system to ISO 9001, ISO 14001 and ISO 45001
- 20 transformer types have passed state type tests in China
- Built to the customer's drawing and requirements, including non-standard voltages and designs
- Energy efficiency classes 1–3 per GB 20052-2024: you can choose a transformer with minimum losses
