High-head slurry pumps ZGB(P)
Horizontal cantilever slurry pumps with a double casing for high head at medium and low slurry concentration. Versions with the (P) suffix are assembled in 3–4 stages in series and deliver slurry over long distances. Used for feeding filter presses and transporting ash and slag at power plants and tailings from processing plants.
Applications
- feeding filter presses
- ash and slag removal at power plants
- long-distance tailings transport
Design
- Single-stage head up to 94 m
- Multistage (P) version: 3–4 stages in series
- Double casing, replaceable wet end
- Impeller clearance adjusted by screws on the frame
Models and specifications
65ZGBdischarge outlet DN 65
High-head slurry pumps ZGB(P)
Pump 65ZGB
- Q, m³/h
- 10,5–31,7
- H, m
- 25,4–61
- n, rpm
- 980–1480
80ZGBdischarge outlet DN 80
High-head slurry pumps ZGB(P)
Pump 80ZGB
- Q, m³/h
- 15,3–56,7
- H, m
- 25,6–91,6
- n, rpm
- 980–1480
100ZGBdischarge outlet DN 100
High-head slurry pumps ZGB(P)
Pump 100ZGB
- Q, m³/h
- 30,9–119,7
- H, m
- 23,9–91,8
- n, rpm
- 980–1480
150ZGBdischarge outlet DN 150
High-head slurry pumps ZGB(P)
Pump 150ZGB
- Q, m³/h
- 64,8–200
- H, m
- 35,2–90
- n, rpm
- 740–980
200ZGB(P)discharge outlet DN 200
High-head slurry pumps ZGB(P)
Pump 200ZGB(P)
- Q, m³/h
- 97,9–300
- H, m
- 38–94,2
- n, rpm
- 740–980
250ZGB(P)discharge outlet DN 250
High-head slurry pumps ZGB(P)
Pump 250ZGB(P)
- Q, m³/h
- 99,4–400
- H, m
- 36,4–90,1
- n, rpm
- 740–980
300ZGB(P)discharge outlet DN 300
High-head slurry pumps ZGB(P)
Pump 300ZGB(P)
- Q, m³/h
- 171,2–533,3
- H, m
- 34,7–93,4
- n, rpm
- 740–980
Flow and head ranges are from the factory catalogue for various speeds and impeller diameters. We select the exact duty point from your data.
