TSPphoto on request
Series photo. Appearance and paint of a specific model — to order.
Vertical sump pumps
Pump 200SV-TSP
Cantilever pumps for sumps and pits: the motor is on top and only the wet end goes into the slurry.
Technical dataper the factory catalogue
- Model
- 200SV-TSP
- Series
- Vertical sump pumps
- Flow Q
- 328–812 m³/h
- Head H
- 22.9–37 m
- Motor power
- up to 110 kW
- Submergence depth
- 1800 mm
- Wet end
- metal or rubber
Price on requestQuoted ex works (EXW) and delivered to site, manufacturing from 30 daysRequest a price
Other models in the series
40PV-TSPsubmergence depth 900 mm
Vertical sump pumps
Pump 40PV-TSP
- Q, m³/h
- 9,72–43,2
- H, m
- 8,2–28
- P, kW
- up to 15
65QV-TSPsubmergence depth 1200 mm
Vertical sump pumps
Pump 65QV-TSP
- Q, m³/h
- 26–100
- H, m
- 9,8–29,2
- P, kW
- up to 30
100RV-TSPsubmergence depth 1500 mm
Vertical sump pumps
Pump 100RV-TSP
- Q, m³/h
- 82,4–373
- H, m
- 17,4–49
- P, kW
- up to 75
150SV-TSPsubmergence depth 1800 mm
Vertical sump pumps
Pump 150SV-TSP
- Q, m³/h
- 140–632
- H, m
- 13,5–36,3
- P, kW
- up to 110
