Vertical sump pumps
Vertical cantilever pumps: the bearing assembly sits above the slurry level and only the wet end goes into the sump. No gland water needed; they work with insufficient suction head.
Interchangeable by connection dimensions with vertical pumps of the SP / SPR series.
Applications
- sumps and pits at processing plants
- mine drainage
- pumping sludge from settling ponds
Design
- No gland water needed
- Level-lowering operation
- Metal or rubber wet end
- Extended shafts for the sump depth
Models and specifications
TG-4DTG / TGH
Vertical sump pumps
Pump TG-4D
- Q, m³/h
- 36–250
- H, m
- 3,5–51
- P, kW
- up to 60
- n, rpm
- 600–1400
TG-6ETG / TGH
Vertical sump pumps
Pump TG-6E
- Q, m³/h
- 180–540
- H, m
- 10–48
- P, kW
- up to 120
- n, rpm
- 800–1400
TG-8FTG / TGH
Vertical sump pumps
Pump TG-8F
- Q, m³/h
- 180–820
- H, m
- 13–50
- P, kW
- up to 260
- n, rpm
- 500–1000
TG-8STG / TGH
Vertical sump pumps
Pump TG-8S
- Q, m³/h
- 180–820
- H, m
- 13–50
- P, kW
- up to 560
- n, rpm
- 500–1000
TG-10GTG / TGH
Vertical sump pumps
Pump TG-10G
- Q, m³/h
- 360–1200
- H, m
- 11–58
- P, kW
- up to 600
- n, rpm
- 400–850
TG-12GTG / TGH
Vertical sump pumps
Pump TG-12G
- Q, m³/h
- 500–3000
- H, m
- 6–66
- P, kW
- up to 600
- n, rpm
- 300–700
TGH-8STG / TGH
Vertical sump pumps
Pump TGH-8S
- Q, m³/h
- 750–1300
- H, m
- 18–80
- P, kW
- up to 560
- n, rpm
- 500–950
TGH-10GTG / TGH
Vertical sump pumps
Pump TGH-10G
- Q, m³/h
- 1400–2700
- H, m
- 28–78
- P, kW
- up to 600
- n, rpm
- 350–700
TGH-14TUTG / TGH
Vertical sump pumps
Pump TGH-14TU
- Q, m³/h
- 700–3400
- H, m
- 20–72
- P, kW
- up to 1200
- n, rpm
- 300–500
TG-16TUTG / TGH
Vertical sump pumps
Pump TG-16TU
- Q, m³/h
- 720–3600
- H, m
- 20–75
- P, kW
- up to 1200
- n, rpm
- 250–500
TG-18TUTG / TGH
Vertical sump pumps
Pump TG-18TU
- Q, m³/h
- 700–4000
- H, m
- 15–50
- P, kW
- up to 1200
- n, rpm
- 200–400
Flow and head ranges are from the factory catalogue for various speeds and impeller diameters. We select the exact duty point from your data.
