Light-duty slurry pumps
More compact and lighter than heavy-duty pumps of the same diameter, and cheaper. At low speed they also handle heavy slurries. MTL models have a metal wet end, RTL models a rubber one for fine and corrosive media.
Interchangeable by connection dimensions with L series pumps.
Applications
- hydraulic transport of tailings
- flotation and thickening circuits
- process water circuits of processing plants
- wastewater treatment plants
Design
- Flow up to 9 100 m³/h
- Metal (MTL) or rubber (RTL) wet end
- Drive via coupling or belt
Models and specifications
MTL-20BMTL / RTL
Light-duty slurry pumps
Pump MTL-20B
- Q, m³/h
- 2,34–10,8
- H, m
- 6–37
- P, kW
- up to 7.5
- n, rpm
- 1400–3000
MTL-50BMTL / RTL
Light-duty slurry pumps
Pump MTL-50B
- Q, m³/h
- 11,5–76
- H, m
- 8,5–46
- P, kW
- up to 15
- n, rpm
- 1400–2800
MTL-75CMTL / RTL
Light-duty slurry pumps
Pump MTL-75C
- Q, m³/h
- 18–151
- H, m
- 4–46,4
- P, kW
- up to 30
- n, rpm
- 900–2400
MTL-100DMTL / RTL
Light-duty slurry pumps
Pump MTL-100D
- Q, m³/h
- 46,8–324
- H, m
- 7–48,3
- P, kW
- up to 60
- n, rpm
- 800–1800
MTL-150EMTL / RTL
Light-duty slurry pumps
Pump MTL-150E
- Q, m³/h
- 115–568,8
- H, m
- 10,5–51,8
- P, kW
- up to 120
- n, rpm
- 800–1500
MTL-200EMTL / RTL
Light-duty slurry pumps
Pump MTL-200E
- Q, m³/h
- 234–910
- H, m
- 9,5–40
- P, kW
- up to 120
- n, rpm
- 600–1100
MTL-250EMTL / RTL
Light-duty slurry pumps
Pump MTL-250E
- Q, m³/h
- 396–1425
- H, m
- 8–30
- P, kW
- up to 120
- n, rpm
- 500–800
MTL-300SMTL / RTL
Light-duty slurry pumps
Pump MTL-300S
- Q, m³/h
- 468–2538
- H, m
- 8–60
- P, kW
- up to 560
- n, rpm
- 400–950
MTL-350SMTL / RTL
Light-duty slurry pumps
Pump MTL-350S
- Q, m³/h
- 650–2800
- H, m
- 10–59
- P, kW
- up to 560
- n, rpm
- 400–840
MTL-400STMTL / RTL
Light-duty slurry pumps
Pump MTL-400ST
- Q, m³/h
- 756–3312
- H, m
- 7–37,5
- P, kW
- up to 560
- n, rpm
- 300–600
MTL-450STMTL / RTL
Light-duty slurry pumps
Pump MTL-450ST
- Q, m³/h
- 1080–4356
- H, m
- 9–40
- P, kW
- up to 560
- n, rpm
- 300–550
MTL-550TUMTL / RTL
Light-duty slurry pumps
Pump MTL-550TU
- Q, m³/h
- 1980–7920
- H, m
- 10–50
- P, kW
- up to 1200
- n, rpm
- 250–475
MTL-650TUMTL / RTL
Light-duty slurry pumps
Pump MTL-650TU
- Q, m³/h
- 2520–9108
- H, m
- 10–55
- P, kW
- up to 1200
- n, rpm
- 200–350
RTL-50BMTL / RTL
Light-duty slurry pumps
Pump RTL-50B
- Q, m³/h
- 9–61
- H, m
- 3–32,4
- P, kW
- up to 15
- n, rpm
- 1200–2600
RTL-75CMTL / RTL
Light-duty slurry pumps
Pump RTL-75C
- Q, m³/h
- 28,8–154,8
- H, m
- 9–43
- P, kW
- up to 30
- n, rpm
- 1100–2300
RTL-100DMTL / RTL
Light-duty slurry pumps
Pump RTL-100D
- Q, m³/h
- 54–288
- H, m
- 12–38
- P, kW
- up to 60
- n, rpm
- 800–1600
RTL-150EMTL / RTL
Light-duty slurry pumps
Pump RTL-150E
- Q, m³/h
- 72–576
- H, m
- 4–38
- P, kW
- up to 120
- n, rpm
- 800–1300
RTL-250EMTL / RTL
Light-duty slurry pumps
Pump RTL-250E
- Q, m³/h
- 396–1425
- H, m
- 8–30
- P, kW
- up to 120
- n, rpm
- 500–800
RTL-300SMTL / RTL
Light-duty slurry pumps
Pump RTL-300S
- Q, m³/h
- 432–1900
- H, m
- 7–41
- P, kW
- up to 560
- n, rpm
- 400–800
RTL-350SMTL / RTL
Light-duty slurry pumps
Pump RTL-350S
- Q, m³/h
- 720–2844
- H, m
- 10–41
- P, kW
- up to 560
- n, rpm
- 400–700
RTL-400STMTL / RTL
Light-duty slurry pumps
Pump RTL-400ST
- Q, m³/h
- 720–3312
- H, m
- 7–51
- P, kW
- up to 560
- n, rpm
- 300–700
RTL-450STMTL / RTL
Light-duty slurry pumps
Pump RTL-450ST
- Q, m³/h
- 1008–4356
- H, m
- 9–48
- P, kW
- up to 560
- n, rpm
- 300–600
RTL-550TUMTL / RTL
Light-duty slurry pumps
Pump RTL-550TU
- Q, m³/h
- 1980–7920
- H, m
- 10–50
- P, kW
- up to 1200
- n, rpm
- 250–475
RTL-650TUMTL / RTL
Light-duty slurry pumps
Pump RTL-650TU
- Q, m³/h
- 2520–9108
- H, m
- 10–39
- P, kW
- up to 1200
- n, rpm
- 200–350
Flow and head ranges are from the factory catalogue for various speeds and impeller diameters. We select the exact duty point from your data.
