High-head slurry pumps
Single-stage cantilever pumps with a reinforced frame and wet end for heads of up to 118 m per stage. Suitable for series installation in several stages on long slurry pipelines.
Interchangeable by connection dimensions with pumps of the HH and H series.
Applications
- long-distance slurry pipelines
- feeding filter presses
- tailings facilities of mining plants
Design
- Single-stage head up to 118 m
- Wet end of high-chrome iron
- Pumps can run in series
Models and specifications
THH-1CTHH
High-head slurry pumps
Pump THH-1C
- Q, m³/h
- 16,2–34,2
- H, m
- 25–92
- P, kW
- up to 30
- n, rpm
- 1400–2200
THH-2DTHH
High-head slurry pumps
Pump THH-2D
- Q, m³/h
- 68–136,8
- H, m
- 25–87
- P, kW
- up to 60
- n, rpm
- 850–1400
THH-3ETHH
High-head slurry pumps
Pump THH-3E
- Q, m³/h
- 126–252
- H, m
- 12–97
- P, kW
- up to 120
- n, rpm
- 600–1400
THH-4STHH
High-head slurry pumps
Pump THH-4S
- Q, m³/h
- 324–720
- H, m
- 30–118
- P, kW
- up to 560
- n, rpm
- 600–1000
THH-6STHH
High-head slurry pumps
Pump THH-6S
- Q, m³/h
- 468–1008
- H, m
- 20–94
- P, kW
- up to 560
- n, rpm
- 500–1000
THH-6TTHH
High-head slurry pumps
Pump THH-6T
- Q, m³/h
- 576–1152
- H, m
- 32–95
- P, kW
- up to 1200
- n, rpm
- 450–725
Flow and head ranges are from the factory catalogue for various speeds and impeller diameters. We select the exact duty point from your data.
