ZJ double-casing slurry pumps
Single-stage horizontal cantilever slurry pumps with a double casing. Designed for high-concentration slurries and high head: feeding filter presses, transporting ash and slag at power plants and tailings from processing plants. Widely used in power generation, metallurgy, mining, coal and chemical industries.
Applications
- feeding filter presses
- ash and slag removal at power plants
- tailings management at processing plants
- building materials and chemical industry
Design
- Double casing: outer casing and replaceable liners
- Seal: gland packing with an expeller
- Designation 100ZJ-I-A36: discharge outlet 100 mm, single stage, impeller diameter 36 cm
- Discharge outlet from 40 to 350 mm
Models and specifications
350ZJ-I-F100ZJ
ZJ double-casing slurry pumps
Pump 350ZJ-I-F100
- Q, m³/h
- 526–2339
- H, m
- 14,9–62,8
- P, kW
- up to 560
- n, rpm
- 300–590
300ZJ-I-A100ZJ
ZJ double-casing slurry pumps
Pump 300ZJ-I-A100
- Q, m³/h
- 464–1826
- H, m
- 15,3–65,2
- P, kW
- up to 450
- n, rpm
- 300–590
300ZJ-I-A95ZJ
ZJ double-casing slurry pumps
Pump 300ZJ-I-A95
- Q, m³/h
- 441–1735
- H, m
- 13,8–58,8
- P, kW
- up to 400
- n, rpm
- 300–590
300ZJ-I-A90ZJ
ZJ double-casing slurry pumps
Pump 300ZJ-I-A90
- Q, m³/h
- 505–1844
- H, m
- 21,2–79,9
- P, kW
- up to 560
- n, rpm
- 400–730
300ZJ-I-A85ZJ
ZJ double-casing slurry pumps
Pump 300ZJ-I-A85
- Q, m³/h
- 477–1742
- H, m
- 18,9–71,3
- P, kW
- up to 450
- n, rpm
- 400–730
300ZJ-I-A70ZJ
ZJ double-casing slurry pumps
Pump 300ZJ-I-A70
- Q, m³/h
- 635–2333
- H, m
- 16,0–76,8
- P, kW
- up to 630
- n, rpm
- 490–980
300ZJ-I-A65ZJ
ZJ double-casing slurry pumps
Pump 300ZJ-I-A65
- Q, m³/h
- 589–2166
- H, m
- 13,8–66,2
- P, kW
- up to 500
- n, rpm
- 490–980
300ZJ-I-A56ZJ
ZJ double-casing slurry pumps
Pump 300ZJ-I-A56
- Q, m³/h
- 395–1568
- H, m
- 9,7–46,0
- P, kW
- up to 250
- n, rpm
- 490–980
250ZJ-I-A103ZJ
ZJ double-casing slurry pumps
Pump 250ZJ-I-A103
- Q, m³/h
- 402–1573
- H, m
- 29,7–110,5
- P, kW
- up to 560
- n, rpm
- 400–730
250ZJ-I-A96ZJ
ZJ double-casing slurry pumps
Pump 250ZJ-I-A96
- Q, m³/h
- 403–1466
- H, m
- 25,4–93,7
- P, kW
- up to 560
- n, rpm
- 400–730
250ZJ-I-A90ZJ
ZJ double-casing slurry pumps
Pump 250ZJ-I-A90
- Q, m³/h
- 378–1374
- H, m
- 22,3–82,4
- P, kW
- up to 450
- n, rpm
- 400–730
250ZJ-I-A85ZJ
ZJ double-casing slurry pumps
Pump 250ZJ-I-A85
- Q, m³/h
- 376–1504
- H, m
- 30,1–128,7
- P, kW
- up to 800
- n, rpm
- 490–980
250ZJ-I-A83ZJ
ZJ double-casing slurry pumps
Pump 250ZJ-I-A83
- Q, m³/h
- 367–1469
- H, m
- 28,7–122,7
- P, kW
- up to 800
- n, rpm
- 490–980
250ZJ-I-A80ZJ
ZJ double-casing slurry pumps
Pump 250ZJ-I-A80
- Q, m³/h
- 354–1416
- H, m
- 26,7–114,0
- P, kW
- up to 710
- n, rpm
- 490–980
250ZJ-I-A78ZJ
ZJ double-casing slurry pumps
Pump 250ZJ-I-A78
- Q, m³/h
- 345–1380
- H, m
- 25,4–108,4
- P, kW
- up to 630
- n, rpm
- 490–980
250ZJ-I-A75ZJ
ZJ double-casing slurry pumps
Pump 250ZJ-I-A75
- Q, m³/h
- 300–1480
- H, m
- 20,8–97,5
- P, kW
- up to 560
- n, rpm
- 490–980
250ZJ-I-A73ZJ
ZJ double-casing slurry pumps
Pump 250ZJ-I-A73
- Q, m³/h
- 292–1441
- H, m
- 19,7–92,4
- P, kW
- up to 500
- n, rpm
- 490–980
250ZJ-I-A70ZJ
ZJ double-casing slurry pumps
Pump 250ZJ-I-A70
- Q, m³/h
- 280–1381
- H, m
- 18,1–84,9
- P, kW
- up to 450
- n, rpm
- 490–980
250ZJ-I-A68ZJ
ZJ double-casing slurry pumps
Pump 250ZJ-I-A68
- Q, m³/h
- 272–1342
- H, m
- 17,1–80,1
- P, kW
- up to 450
- n, rpm
- 490–980
250ZJ-I-A65ZJ
ZJ double-casing slurry pumps
Pump 250ZJ-I-A65
- Q, m³/h
- 299–1249
- H, m
- 15,4–71,0
- P, kW
- up to 315
- n, rpm
- 490–980
250ZJ-I-A63ZJ
ZJ double-casing slurry pumps
Pump 250ZJ-I-A63
- Q, m³/h
- 290–1211
- H, m
- 14,4–66,7
- P, kW
- up to 315
- n, rpm
- 490–980
250ZJ-I-A60ZJ
ZJ double-casing slurry pumps
Pump 250ZJ-I-A60
- Q, m³/h
- 276–1153
- H, m
- 13,1–60,5
- P, kW
- up to 280
- n, rpm
- 490–980
200ZJ-I-A85ZJ
ZJ double-casing slurry pumps
Pump 200ZJ-I-A85
- Q, m³/h
- 221–907
- H, m
- 32,0–133,7
- P, kW
- up to 560
- n, rpm
- 490–980
200ZJ-I-A75ZJ
ZJ double-casing slurry pumps
Pump 200ZJ-I-A75
- Q, m³/h
- 225–900
- H, m
- 22,8–102,9
- P, kW
- up to 355
- n, rpm
- 490–980
200ZJ-I-A73ZJ
ZJ double-casing slurry pumps
Pump 200ZJ-I-A73
- Q, m³/h
- 219–876
- H, m
- 21,6–97,5
- P, kW
- up to 355
- n, rpm
- 490–980
200ZJ-I-A70ZJ
ZJ double-casing slurry pumps
Pump 200ZJ-I-A70
- Q, m³/h
- 205–976
- H, m
- 19,4–86,4
- P, kW
- up to 315
- n, rpm
- 490–980
200ZJ-I-A68ZJ
ZJ double-casing slurry pumps
Pump 200ZJ-I-A68
- Q, m³/h
- 199–948
- H, m
- 18,3–81,5
- P, kW
- up to 315
- n, rpm
- 490–980
200ZJ-I-A65ZJ
ZJ double-casing slurry pumps
Pump 200ZJ-I-A65
- Q, m³/h
- 235–950
- H, m
- 16,4–72,0
- P, kW
- up to 250
- n, rpm
- 490–980
200ZJ-I-A63ZJ
ZJ double-casing slurry pumps
Pump 200ZJ-I-A63
- Q, m³/h
- 228–921
- H, m
- 15,4–67,6
- P, kW
- up to 250
- n, rpm
- 490–980
200ZJ-I-A60ZJ
ZJ double-casing slurry pumps
Pump 200ZJ-I-A60
- Q, m³/h
- 218–870
- H, m
- 13,9–62,0
- P, kW
- up to 185
- n, rpm
- 490–980
200ZJ-I-A58ZJ
ZJ double-casing slurry pumps
Pump 200ZJ-I-A58
- Q, m³/h
- 211–841
- H, m
- 13,0–57,9
- P, kW
- up to 185
- n, rpm
- 490–980
150ZJ-I-A71ZJ
ZJ double-casing slurry pumps
Pump 150ZJ-I-A71
- Q, m³/h
- 142–552
- H, m
- 21,8–93,8
- P, kW
- up to 220
- n, rpm
- 490–980
150ZJ-I-A70ZJ
ZJ double-casing slurry pumps
Pump 150ZJ-I-A70
- Q, m³/h
- 93–401
- H, m
- 20,0–91,2
- P, kW
- up to 185
- n, rpm
- 490–980
150ZJ-I-A65ZJ
ZJ double-casing slurry pumps
Pump 150ZJ-I-A65
- Q, m³/h
- 150–600
- H, m
- 17,4–75,7
- P, kW
- up to 200
- n, rpm
- 490–980
150ZJ-I-A63ZJ
ZJ double-casing slurry pumps
Pump 150ZJ-I-A63
- Q, m³/h
- 146–582
- H, m
- 16,3–71,1
- P, kW
- up to 185
- n, rpm
- 490–980
150ZJ-I-A60ZJ
ZJ double-casing slurry pumps
Pump 150ZJ-I-A60
- Q, m³/h
- 135–550
- H, m
- 14,7–63,5
- P, kW
- up to 160
- n, rpm
- 490–980
150ZJ-I-A58ZJ
ZJ double-casing slurry pumps
Pump 150ZJ-I-A58
- Q, m³/h
- 131–532
- H, m
- 13,7–59,3
- P, kW
- up to 132
- n, rpm
- 490–980
150ZJ-I-C58ZJ
ZJ double-casing slurry pumps
Pump 150ZJ-I-C58
- Q, m³/h
- 134–596
- H, m
- 12,8–61,0
- P, kW
- up to 160
- n, rpm
- 490–980
150ZJ-I-A57ZJ
ZJ double-casing slurry pumps
Pump 150ZJ-I-A57
- Q, m³/h
- 95–427
- H, m
- 13,2–56,3
- P, kW
- up to 110
- n, rpm
- 490–980
150ZJ-I-A55ZJ
ZJ double-casing slurry pumps
Pump 150ZJ-I-A55
- Q, m³/h
- 124–504
- H, m
- 12,3–53,4
- P, kW
- up to 110
- n, rpm
- 490–980
150ZJ-I-A50ZJ
ZJ double-casing slurry pumps
Pump 150ZJ-I-A50
- Q, m³/h
- 115–460
- H, m
- 9,5–43,1
- P, kW
- up to 75
- n, rpm
- 490–980
150ZJ-I-A48ZJ
ZJ double-casing slurry pumps
Pump 150ZJ-I-A48
- Q, m³/h
- 111–442
- H, m
- 8,7–39,7
- P, kW
- up to 75
- n, rpm
- 490–980
150ZJ-I-A42ZJ
ZJ double-casing slurry pumps
Pump 150ZJ-I-A42
- Q, m³/h
- 142–550
- H, m
- 12,1–62,8
- P, kW
- up to 132
- n, rpm
- 700–1480
100ZJ-I-A50ZJ
ZJ double-casing slurry pumps
Pump 100ZJ-I-A50
- Q, m³/h
- 85–360
- H, m
- 20,5–100,2
- P, kW
- up to 160
- n, rpm
- 700–1480
100ZJ-I-A46ZJ
ZJ double-casing slurry pumps
Pump 100ZJ-I-A46
- Q, m³/h
- 79–331
- H, m
- 17,3–84,8
- P, kW
- up to 132
- n, rpm
- 700–1480
100ZJ-I-A42ZJ
ZJ double-casing slurry pumps
Pump 100ZJ-I-A42
- Q, m³/h
- 66–275
- H, m
- 14,7–70,8
- P, kW
- up to 90
- n, rpm
- 700–1480
100ZJ-I-A39ZJ
ZJ double-casing slurry pumps
Pump 100ZJ-I-A39
- Q, m³/h
- 61–255
- H, m
- 12,6–61,0
- P, kW
- up to 75
- n, rpm
- 700–1480
100ZJ-I-A36ZJ
ZJ double-casing slurry pumps
Pump 100ZJ-I-A36
- Q, m³/h
- 61–245
- H, m
- 9,7–49,5
- P, kW
- up to 55
- n, rpm
- 700–1480
100ZJ-I-A33ZJ
ZJ double-casing slurry pumps
Pump 100ZJ-I-A33
- Q, m³/h
- 56–225
- H, m
- 8,2–41,6
- P, kW
- up to 45
- n, rpm
- 700–1480
80ZJ-I-A52ZJ
ZJ double-casing slurry pumps
Pump 80ZJ-I-A52
- Q, m³/h
- 51–242
- H, m
- 22,1–109,8
- P, kW
- up to 160
- n, rpm
- 700–1480
80ZJ-I-A42ZJ
ZJ double-casing slurry pumps
Pump 80ZJ-I-A42
- Q, m³/h
- 61–204
- H, m
- 14,4–70,4
- P, kW
- up to 75
- n, rpm
- 700–1480
80ZJ-I-A39ZJ
ZJ double-casing slurry pumps
Pump 80ZJ-I-A39
- Q, m³/h
- 57–189
- H, m
- 12,4–60,7
- P, kW
- up to 55
- n, rpm
- 700–1480
80ZJ-I-A36ZJ
ZJ double-casing slurry pumps
Pump 80ZJ-I-A36
- Q, m³/h
- 46–190
- H, m
- 9,6–51,4
- P, kW
- up to 45
- n, rpm
- 700–1480
80ZJ-I-A33ZJ
ZJ double-casing slurry pumps
Pump 80ZJ-I-A33
- Q, m³/h
- 43–174
- H, m
- 8,0–43,2
- P, kW
- up to 37
- n, rpm
- 700–1480
65ZJ-I-A30ZJ
ZJ double-casing slurry pumps
Pump 65ZJ-I-A30
- Q, m³/h
- 23–79
- H, m
- 7,4–34,8
- P, kW
- up to 15
- n, rpm
- 700–1480
65ZJ-I-A27ZJ
ZJ double-casing slurry pumps
Pump 65ZJ-I-A27
- Q, m³/h
- 20–71
- H, m
- 6,0–28,2
- P, kW
- up to 11
- n, rpm
- 700–1480
50ZJ-I-A50ZJ
ZJ double-casing slurry pumps
Pump 50ZJ-I-A50
- Q, m³/h
- 27–111
- H, m
- 22,3–110,7
- P, kW
- up to 90
- n, rpm
- 700–1480
50ZJ-I-A46ZJ
ZJ double-casing slurry pumps
Pump 50ZJ-I-A46
- Q, m³/h
- 23–94
- H, m
- 17,9–85,8
- P, kW
- up to 55
- n, rpm
- 700–1480
50ZJ-I-A33ZJ
ZJ double-casing slurry pumps
Pump 50ZJ-I-A33
- Q, m³/h
- 12–54
- H, m
- 7,7–42,5
- P, kW
- up to 18.5
- n, rpm
- 700–1480
40ZJ-I-A19ZJ
ZJ double-casing slurry pumps
Pump 40ZJ-I-A19
- Q, m³/h
- 8–35
- H, m
- 12,8–57,1
- P, kW
- up to 15
- n, rpm
- 1430–2930
40ZJ-I-A17ZJ
ZJ double-casing slurry pumps
Pump 40ZJ-I-A17
- Q, m³/h
- 4–23,4
- H, m
- 9,0–44,6
- P, kW
- up to 7.5
- n, rpm
- 1400–2900
Flow and head ranges are from the factory catalogue for various speeds and impeller diameters. We select the exact duty point from your data.
