Flue gas desulfurization pumps (FGD)
Pumps for circulating limestone and gypsum slurry in flue gas desulfurization systems at thermal power plants. Also suitable for slurries with corrosive solids in the metallurgical, mining, coal and chemical industries. TL(R) has a double casing, DT a single casing.
Applications
- FGD absorbers at power plants
- limestone and gypsum slurry circulation
- corrosive slurries in metallurgy and chemicals
Design
- Efficiency from 76 to 90 % per catalogue
- TL(R) — double casing, DT — single casing
- Mechanical seal
- Metal or rubber wet end
Models and specifications
500TL(R)Efficiency 85 %
Flue gas desulfurization pumps (FGD)
Pump 500TL(R)
- Q, m³/h
- 3750
- H, m
- 25
- n, rpm
- 725
600TL(R)Efficiency 88 %
Flue gas desulfurization pumps (FGD)
Pump 600TL(R)
- Q, m³/h
- 6300
- H, m
- 25,5
- n, rpm
- 620
700TL(R)Efficiency 87 %
Flue gas desulfurization pumps (FGD)
Pump 700TL(R)
- Q, m³/h
- 6840
- H, m
- 26
- n, rpm
- 485
800TL(R)Efficiency 90 %
Flue gas desulfurization pumps (FGD)
Pump 800TL(R)
- Q, m³/h
- 9360
- H, m
- 31
- n, rpm
- 485
400DT-A65Efficiency 88.3 %
Flue gas desulfurization pumps (FGD)
Pump 400DT-A65
- Q, m³/h
- 1134–3330
- H, m
- 8,8–31,1
- n, rpm
- 490–742
500DT-A70Efficiency 86.4 %
Flue gas desulfurization pumps (FGD)
Pump 500DT-A70
- Q, m³/h
- 1908–4399
- H, m
- 9,3–32,5
- n, rpm
- 490–742
500DT-A76Efficiency 86.7 %
Flue gas desulfurization pumps (FGD)
Pump 500DT-A76
- Q, m³/h
- 1555–3881
- H, m
- 9,9–27,9
- n, rpm
- 450–595
600DT-A82Efficiency 85.9 %
Flue gas desulfurization pumps (FGD)
Pump 600DT-A82
- Q, m³/h
- 1664–5600
- H, m
- 5,2–27,8
- n, rpm
- 300–595
700DT-B78Efficiency 84.7 %
Flue gas desulfurization pumps (FGD)
Pump 700DT-B78
- Q, m³/h
- 3378–7200
- H, m
- 10,0–21,8
- n, rpm
- 400–595
700DT-A83Efficiency 88.3 %
Flue gas desulfurization pumps (FGD)
Pump 700DT-A83
- Q, m³/h
- 2677–6491
- H, m
- 8,7–30,2
- n, rpm
- 400–595
700DT-A90Efficiency 76.8 %
Flue gas desulfurization pumps (FGD)
Pump 700DT-A90
- Q, m³/h
- 3551–8988
- H, m
- 10,0–33,8
- n, rpm
- 400–595
800DT-A90Efficiency 76.0 %
Flue gas desulfurization pumps (FGD)
Pump 800DT-A90
- Q, m³/h
- 4104–10690
- H, m
- 7,8–27,8
- n, rpm
- 400–595
900DT-F110Efficiency 80.1 %
Flue gas desulfurization pumps (FGD)
Pump 900DT-F110
- Q, m³/h
- 4907–14076
- H, m
- 8,5–32,7
- n, rpm
- 300–490
Flow and head ranges are from the factory catalogue for various speeds and impeller diameters. We select the exact duty point from your data.
